Heavy Duty Checkweigher AD-4942B

Large Capacity (15kg/31kg) Checkweighers with LCD touchscreen

Photo: AD-4942B-30K fitted with optional parts           (conveyor stand, indicator stand, and attachment kit for display stand) AD-4942B series are Checkweighers that are fitted with a 7-inch color touchscreen and can weigh heavy items packaged in carton boxes or placed on a pallet. Brochure (PDF 1.7MB)

Please send your inquiry here

Features

Large capacity Checkweigher: 15 kg or 31 kg Operation screen: 7-inch color touchscreen Storable product info: Up to 1,000 products (including product images) Connectable to Barcode Reader allowing automatic switching of the product to be weighed. (*Barcode reader shall be prepared by the customer.) Data such as Weighing Result and Operational History can be output to a USB flash drive. Weighing Data management and User management Various communication methods: RS-232C, RS-485, a USB flash drive, LAN cable, wireless LAN, etc. Selectable Weighing modes: Passing weighing, Stop weighing, or Static weighing Feedback control by weighing result

Application Example

Final Inspection of Packaged Boxes

Can be used as the final inspection step in your production line by checking whether some items in a box are missing by weighing the box. Many logistics centers and production plants for food, cosmetics, machine parts industry, etc., adopt a checkweigher in their final inspection phase.

Feedback Control by Weighing Result

Weighing results can be fed back to another system upstream of the production line. *Image below is an example of feedback to a filling machine.

Advantages

Easy Operation

Operated by a 7-inch color touchscreen. GUI on the touchscreen makes it very easy to understand and operate. Up to 1,000 products can be registered and categorized into 10 different groups. An image of each product can also be quickly and easily registered from a USB flash drive. Configuring settings is very simple.

Connectable to Barcode Reader

AD-4942B can be connected to a barcode reader (*) in the same processing line. By reading the barcode on a product, the product settings are automatically switched to those of the scanned product.

*Barcode reader shall be prepared by the customer.

Data Management

Weighing data can be automatically summarized and can be output to a USB flash drive as a PDF file. The data is helpful for management of HACCP.

AD-4942B can automatically record Weighing History and Operational History. The records can be displayed on the touchscreen and can be output to a USB flash drive as csv files. AD-4942B can display and output checkweighing summary data and X/R control charts. X Control Chart shows average values and R Control Chart shows the gap between maximum and minimum values.

Operational History shows a record of the changes made to the settings and is also helpful for management of HACCP. To operate the device, user name and user level are registered. For each user registered, you can limit the operations they can perform depending on their user level. Inadvertent operation can be avoided by assigning each user a user level from the four levels below.

Various Communication Methods

AD-4942B has various interfaces: RS-232C, RS-485, a USB flash drive, LAN cable, wireless LAN, etc. AD-4942B can communicate with devices supported by Modbus without a program through serial communication and/or TCP/IP communication.

(Machines/devices that communicate via Control I/O is connected via a relay board in the weighing unit.)

Wireless LAN

Weighing data can be checked on tablets, smartphones, laptops, etc., via Wireless LAN. *Wireless LAN can be used depending on the regulations in your region. *Wireless LAN receiving sensitivity depends on the radio wave environment.   Caution is required when performing continuous monitoring.

*The above is an example from a different model, but the format is the same as the AD-4942B series.

Remote Maintenance

Touchscreen can be operated from a PC via a LAN cable connection using device operation software for PC. By utilizing remote control software to control another PC, the touchscreen can be operated from another PC. - This is useful for remote maintenance since engineers can check machine settings even if the AD-4942B is in a remote place. (Please prepare separately, a LAN cable, PCs, device operation software for PC and remote-control software.)

Selectable Weighing modes (Automatic operation)

Passing weighing: Weighing without stopping conveyor while product is passed along the conveyor. Stop weighing: Weighing with stopping conveyor after the detected product enters the conveyor. Static weighing: Weighing with stopping conveyor after detected product enters the conveyor and is in a stable state.

Specifications

Weighing Unit

Model AD-4942B-15K AD-4942B-30K Electric frequency 50 Hz 60 Hz 50 Hz 60 Hz Capacity 15 kg 31 kg Accuracy ±10 g ±20 g Readability 2 g 5 g Weighing unit kg, g, lb and oz (lb and oz can be used in U.S.A. version.) Conveyor speed 11.2 m/min 13.4 m/min 14.5 m/min 17.4 m/min Throughput 18 pcs/min 22 pcs/min 16 pcs/min 19 pcs/min Max. size of the weighed product Length 300 mm 280 mm 500 mm 480 mm Width 350 mm 350 mm 450 mm 450 mm Height 300 mm 300 mm 500 mm 500 mm Conveyor Roller conveyor Roller conveyor Control I/O 5 input points (via relay board, NPN open collector) 5 output points (via relay board, AC 250 V, 5 A or DC 30 V, 5 A) Power Drive roller* AC 200 V, ±10 % (3 Phases, 0.5 A) AC 200 V, ±10 % (3 Phases, 0.6 A) Indicator AC 100-240 V (+10 %, -15 %, approx. 30VA) AC 100-240 V (+10 %, -15 %, approx. 30VA) *Please prepare inverter or transformer for the area where voltage is other than 200 V.

Indicator

Model AD-4942B-15K AD-4942B-30K Analog unit Input sensitivity Over 0.15 μV/d (d=minimum division) Zero adjustment range -35 mV to +35 mV (-7 mV/V to +7 mV/V) Load cell excitation DC 5 V, 60 mA up to 4 load cells (350 Ω) Remote sensing function included Temperature coefficients Zero: ±0.02 μV/℃ (Typ.) Span: ±3 ppm/℃ (Typ.) Nonlinearity 0.005 % of F.S. Sampling rate 4,000 times per second Digital unit Number of digits 0-999,999 d Display 7-inch color TFT LCD with touchscreen Registered products Number of product registration Up to 1,000 products General specifications Operating temperature -10 to 50 ℃ Operating humidity 85 % RH or less (no condensation) Dust/water protection Compliant with IP65 (when mounted on a panel) *Requires option AD-4412-10. Standard interface Communication interface RS-232C, RS-485, USB2.0, LAN, Wireless LAN

Options

AD-4942-07 Conveyor stand for AD-4942B-15K AD-4942-08 Conveyor stand for AD-4942B-30K/AD-4943B-30K AD-4412-02* Relay with 9 output points AC 250 V, 3A or DC 30 V, 3A AD-4412-05* Parallel I/O DI 16 points, DO 16 points (NPN open collector DC 40V, 50 mA) AD-4412-07* Analog output 1 ch 4-20 mA or 0-10 V AD-4412-17* Additional analog output module 4-20 mA or 0-10 V (Maximum 4ch by adding 3 pcs of AD-4412-17) AD-4402-25 Indicator stand AD-4412-11 Attachment kit for stand (Required when AD-4402-25 is selected) AD-4412-10 Panel mount bracket *These options are assembled at the factory only when the equipment is first assembled.   These options cannot be added after the equipment is shipped from the factory.
