| Model |
LCB27K006 |
LCB27K010 |
LCB27K015 |
LCB27K020 |
| Rated capacity (R.C.) |
58.8N (6 kg) |
98 N (10 kg) |
147 N (15 kg) |
196 N (20 kg) |
| Allowable moment |
2.08 N m |
3.47 N m |
5.20 N m |
6.93 N m |
| Rated deflection |
0.30 mm |
0.15 mm |
0.15 mm |
0.17 mm |
| Natural frequency |
335 Hz |
503 Hz |
598 Hz |
666 Hz |
| Weight |
96 g |
107 g |
108 g |
108 g |
| Rated output (R.O.) |
2 mV/V ± 10 % |
| Combined error |
0.02 % of R.O. |
| Non-linearity |
0.012 % of R.O. |
| Hysteresis |
0.012 % of R.O. |
| Repeatability |
0.011 % of R.O. |
| Recommended excitation voltage |
5 to 12 VDC |
| Maximum excitation voltage |
15 VDC |
| Zero balance |
±5 % of R.O. |
| Input terminal resistance |
420 Ω ± 30 Ω |
| Output terminal resistance |
350 Ω ± 5 Ω |
| Insulation resistance |
Greater than 2000 MΩ at 50 VDC |
| Temperature effect on zero point |
0.023 % of R.O./10 °C |
| Weight |
0.5 kg |
| Temperature effect on span |
0.014 % of Load/10 °C Typ. |
| Temperature compensation range |
-10 to 40 °C |
| Operating temperature range |
-10 to 40 °C |
| Safe overload |
150 % of R.C. |
| Ultimate overload |
200 % of R.C. |
| Cable |
φ3.5, 4-cpre shielded cable, 0.4 m |
| Dustproof/waterproof |
IP65 |
| Material |
Aluminum |
| Maximum platform size |
300 x 300 mm |
Compact design: 100 mm length x 15 mm height
