LC-4221 (Stainless Steel)
Stainless steel body construction protection from water, moisture and corrosion
LC-4221
Capacity Model No.
10 kgf LC4221-K010
20 kgf LC4221-K020
50 kgf LC4221-K050
100 kgf LC4221-K100
200 kgf LC4221-K200
300 kgf LC4221-K300
Features
Hermetically sealed with stainless steel bellows protects from water and moisture
Stainless steel body is ideal protection from corrosion
Compact size and lightweight
For both tension and compression usage
Dual guided cantilever design for high accuracy
Can be used for multi-point weighing
Temperature compensation maintains both zero and span from -10 °C to +60 °C (+14 °F to +140 °F)
Specifications
Rated capacities....................10 kgf, 20 kgf, 50 kgf, 100 kgf, 200 kgf, 300 kgf
Rated output..........................2 mV/V ± 0.2%
Maximum safe overload...........200% of rated capacity
Combined error......................± 0.05% of rated output
Creep...................................± 0.1 % of rated capacity/hour
Zero balance.........................1% of rated capacity
Compensated
temperature range.................-10 °C to +60 °C/+14 °F to +140 °F
Recommended
excitation voltage..................12 V
Maximum
excitation voltage...................15 V
Input terminal resistance .......Approximately 400 Ω
Output terminal resistance....350 Ω ± 3.5 Ω
Insulation resistance............Greater than 5,000 MO at DC50 V
Temperature effect
Zero......................................0.007% rated output/°C
Span.........................................0.002% rated output/°C Typ.
Cable length...........................5 rn/195 inches


  Drawing
