AD-4402
Performance many operations, from batch weighing to field bus networking applications
AD-4402
PDFBrochure (PDF 1,156KB)
PDFManual (PDF 1,911KB)

Features
100 times/sec. High speed sampling.
High display resolution to 16,000 counts.
Up to 1 million counts of A/D resolution.
Large and easy to see blue Vacuum Fluorescent Display (VFD).
Uses a ten - key pad and function button that are designed for ease of operation and understanding.
The main display has a 7 - digit VFD with 18mm tall characters.
The sub display has a total of 54 5mm - tall dot matrix characters and displays the values and error comments.
Pre-programmed with multiple sequences and functions for filling machines, simple mixing machines
and a weight-checker and other applications.
Stores 100 data for raw materials and 100 data for mixing codes.
RS-485 Serial Output (Current Loop) standard feature allows you to link up to 32 units to the display.
The Monitor Function shows each operating interface and provides a confirmation on the display.
The compact body meets DIN requirements, while minimizing the depth of the indicator to135mm.
With the proper optional interface, the AD-4402 is compatible with CC-Link, Device Net, PROFIBUS.
Standard Modbus function available.

Options
OP-01 Parallel BCD Output
OP-02 Relay Output
OP-03 RS-422/RS-485 I/O
OP-04 RS-232C I/O
OP-05 Parallel I/O
OP-07 Analog Output
OP-10 Stainless Steel Mounting Panel to replace AD-4325A
OP-20 CC Link Interface
OP-21 Device Net Interface
OP-22 PROFIBUS Interface

Download file
AD4402-21 (DeviceNet interface) EDS file

AD4402-22 (PROFIBUS interface) GSD file
The GSD file is the AD4402-22 device description file which is used for setting the parameters of the AD4402-22 with the PROFIBUS class 1 master.

CADCAD File(DXF) Some characters may be garbled as the original CAD data is in Japanese.
