 The Automotive Testing Expo 2006 CHINA was held from September 6th to 8th at the Shanghai Everbright Convention & Exhibition Center in China. This exhibition is well known throughout the world's leading automotive test equipment manufacturers and test service providers. However, this was the first time it was being held in Asia and it featured exhibits from more than 140 companies from all over the world.
|

|
A&D Technology, Inc., which is based in the US, had its own booth at this event and they displayed the following state-of-the-art products:
|
The REDLINE CAS II is the latest combustion analysis system, which has added the benefit of portability to its conventional model. Therefore this product can be ideally used for both in-vehicle and test cell applications. For in-vehicle applications, clearly labeled BNC connectors are mounted to the top of the cabinet, allowing for easy connection to engine sensors. A built-in 12VCD power supply eliminates the need for special power inverters. Using an optional mounting bracket the system can be secured to the floor, or even strapped in with a seat belt. The portability of the RedLine CAS II is also useful for test cell applications where combustion analysis is shared among several test cells. The convenient cable connections and compact size make moving the system from one test cell to another a quick and easy task. For further details,please click http://www.aanddtech.com/ProdServ/combanal/rcas2.htm
|

|
iTest is a Powerful Data Acquisition & Control Software for Powertrain Testing. It executes a predefined test schedule by coordinating the dynamometer and throttle systems, along with data acquisition from sensors on the test article or in-cell instruments. iTest achieves this level of functionality through an intuitive configuration editor and user-friendly operator GUI, while employing international standards for connectivity to the test cell instruments. For further details,please click http://www.aanddtech.com/ProdServ/datacq/testaut.htm
|
|
iConnect is the ultimate solution for minimizing cables in test cell environments. The iCONNECT I/O system combines the benefits of a distributed network with high-quality I/O channels. The resulting system provides for minimal cabling and the ability to place I/O where it is needed. This allows the system to be easily modified for a variety of testing needs. For further details,please click http://www.aanddtech.com/ProdServ/datacq/iCONNECT.htm
|
|
The iCentral Information and Process Management suite is a collection of tools that enhances the management of any test lab from a central point of access. A lab manager can monitor any test cells with the A&D iView Web Server, facilitating remote monitoring of the activity in that cell. iCentral also provides a central location for data archiving and retrieval for all test cells, streamlining the process for accessing and sharing required data. For further details,please click http://www.aanddtech.com/ProdServ/labmanage/helios.htm
|
A&D Technology also displayed the AD5435 Engine Full Pass RCP (rapid control prototyping) System. This demo system is a simple application in engine control. The system detects the engine crankshaft timing using a missing teeth mechanism (Variable Reluctance sensor, gear with basic teeth number of 60 and 2 missing teeth), and then controls the ignition timing, injection timing and duration, etc. based on the speed and timing information. The Graphical User Interface shows the engine speed and the instantaneous angle. The control parameters (ignition timing, fuel injection duration, etc) can be adjusted through the Virtual Console interface.
|

|
For more detailed information, please visit A&D Technology ’s website at http://www.aanddtech.com/
|
A&D Co. Ltd. Japan displayed the following products:
The AD5435 is a high-speed measurement and control system, which can be easily customized for a wide range of applications. With the S-function program, which is supplied by A&D, this product is easy-to-use for hardware-in-the-loop simulation and rapid prototyping, especially for automotive ECU development.
|
|
The image below shows the AD5435 with a mini DC motor bench kit. This kit is a prototyping model for controlling a DC motor. It consists of the AD5435 controller, AD5430-18 vehicle PWM output board, DC brushless motor with resolver and other circuits on board. With this kit, it is possible to perform velocity control and electronic current control. The programming logics developed in this kit can be implemented into real automotive ECU for hybrid vehicles, electric vehicles, electric power steering and so on.
|
 |
 |
| |
Please click this to enlarge. |
|
We also exhibited the AD5450 diesel engine injection kit at this Expo. This
kit enables diesel engine control as well as multistage injection and
current control to develop an ECU for a diesel engine. The AD5450 is a RPT
(Rapid ProtoTyping) platform specifically designed for in-vehicle applications.
This function makes stable operations possible with a multi-CPU structure.
Therefore its engine-angle synchronous processing and time-synchronous
processing are completely independent. This product is currently only
available in Japan.
|
 |
 |
 |
| |
|
Please click this to enlarge. |
|
The WFS is a wheel force sensor, which enables the measurement of 6-component forces in a wheel in real time at 0.1% resolution. The main feature is the 6-component wheel force output. This product improves both mileage performance and driving comfort in the area of vehicle development. The main features are as follows:
-High resolution: 6N 1/4000
-High speed response: 1ms
-Light weight: 3.2kg
-Digital data links: can be linked with CAN or Ethernet
|

|
The RTS is an advanced rotating shaft torque meter with wireless communication of digital data possible by employing A&D’s advanced weighing techniques in a rotating system. These techniques compensate for radial and thrust forces and offer increased torque measurement accuracy. The RTS’s Model-based Real-Time Simulation results are 10 times more accurate than conventional methods.
-Torque rating: 500-2k Nm
-Overall accuracy: 0.03%
-Maximum Rotational Speed: 9000rpm
|

|
The AD3651 is an FFT analyzer, which can perform functions such as in-vehicle order tracking and MIMO analysis. With the in-vehicle option kit, you can use the AD3651 anywhere, such as inside a vehicle, in the field or in a lab. One of its significant features is its scalability from 4,8, to 16 channels in a single A4 size front end. Expansion to a 32-ch configuration is obtained by a synchronized connection of two 16-channel front ends. For further details,please click http://www.aandd.jp/products/test_measuring/fft/ad3651.htm
Main features are as follows.
-User-friendly graphical user interface, with professional performance,
-Compact front-end of true ISO A4 size (210 x 297mm)
-Scalable and flexible
-Data integrity and compatibility.
|

|
Last but certainly not least is our AD3552, a performance enhanced FFT comparator, which provides noise and vibration analysis that instantaneously delivers “OK” or “NG” (not good) results for product testing of bearings, motor, etc. in a manufacturing line. For further details,please click http://www.aandd.jp/products/test_measuring/ad3552/ad3552.html
Main features are as follows:
-Compact, lightweight 1 x 1.4 DIN enclosure easily mounted into rack
-Designed for comparator use, easy to handle
-Compatible with Ethernet
-Central control from a PC
|

|
We were extremely happy with the turnout and recognition of A&D's state-of-the-art products and we are looking forward to pursuing business in the Chinese market as soon as possible. We are also planning to have a booth at next year's Testing Expo CHINA from September 12th to 13th, 2007. Please visit http://www.testing-expo.com for more details. We encourage any enquiries about our products and hope to see you next year at Testing Expo CHINA 2007.
|
